standard plastic granulator

working method

At the core of these granulators is an open rotor equipped with robust knives. These are arranged in a double-scissor or V-shape and work together with stationary knives in the cutting chamber. While the rotor works at high speed, the material is continuously cut until it reaches the desired size through a sieve filter.

Operation and Technical Features

Working method:

At the core of these granulators is an open rotor equipped with robust knives. These are arranged in a double-scissor or V-shape and work together with stationary knives in the cutting chamber. While the rotor works at high speed, the material is continuously cut until it reaches the desired size through a sieve filter.

Technical specifications:

• Knife: Made from high carbon and chromium D2 steel for exceptional durability.

• sieve filter: Adjustable sieve sizes from 10 mm to 100 mm for precise control of granule size.

• Hydraulic access: Hydraulic support facilitates blade adjustment and maintenance.

• Material compatibility: Suitable for processing bottles, films and small solid plastics.

Applications and Benefits

Applications:

• plastic bottles: Efficient shredding of PET bottles into granules for recycling.

• plastic films: Precise processing of films of different thicknesses.

• Solid plastics: Easy processing of small, solid plastic components.

Optional features:

Wet granulator models are available and include:

• Rubber seals and water inlet to cool the blades.

• Effective heat dissipation to ensure consistent cutting performance.

Advantages:

Investing in premium standard plastic granulators means:

• Improved efficiency and quality in recycling processes.

• Durability and cost efficiency thanks to robust construction.

• Increased flexibility for various recycling applications.

model	Rotor Diameter	Rotor Width	Rotating Speed	Approx. Output	Motor Power
RTM600	⌀450mm	600mm	400-600 rpm	300 kg/h	37KW
RTM800	⌀500mm	800mm	400-600 rpm	600 kg/h	45KW
RTM1000	⌀600mm	1000mm	400-600 rpm	900 kg/h	75KW
RTM1200	⌀700mm	1200mm	400-600 rpm	1200 kg/h	90KW
